225/325/525-gallon Plastic Horizontal Leg Tank | Norwesco

Gallon Capacity

225

325

525

Dimensions

225: 49" Length x 38" Width x 41" Height

325: 68" Length x 38" Width x 43" Height

525: 71" Length x 49" Width x 54" Height

Weight

225: 72 lbs

325: 99 lbs

525: 139 lbs

Manway

225: 8" Threaded Vented Lid

325: 16" Threaded Vented Lid

525: 16" Threaded Vented Lid

Inlet

NO FTG

Outlet

225: 2" PP Female NPT Bulkhead Fitting

325: 2" PP Female NPT Bulkhead Fitting

525: 2" PP Female NPT Bulkhead Fitting

Orientation

Material

UV Inhibitors

Manufacturer

Manufacturer Part Number

225: 40299

325: 40217

525: 40181
